Sony TL50 - Video Conferencing

Video
Standards
H.261, H263, H.263+, H.263++, H.264,
H.263 Interlaced SIF, MPEG-4, SP@L3
Resolution
QCIF (176 x 144), CIF (352 x 288)
Frame Rate
Maximum 30 frames
Bit Rate
Up to 768 Kb/s in H.320 (Including Audio)
Up to 2 Mb/s in H.323 (Including Audio)

Audio
Bandwidth and Coding
G.711: 3.4 kHz at 56/64 Kb/s
G.722: 7.0 kHz at 48/56/64 Kb/s
G.722.1: 7.0 kHz at 24/32 Kb/s (H.323)
G.728: 3.4 kHz at 16 Kb/s
G.723.1: 3.4 kHz at 5.3/6.3 Kb/s (H.323)
G.729: 3.4 kHz at 8 Kb/s (H.323)
MPEG-4 AAC (mono) 14 kHz at 64 and 96 Kb/s (H.323) at 48 Kb/s (H.320)

Integrated Display
LCD - 20" Widescreen TFT
Aspect Ratio - 16.9
Resolution - 1280 x 768 (WXGA)
Brightness - 400 Cd/m2 (maximum)
Response - Less than 15 ms
Contrast Ratio - 500:1
Viewing Angle - Greater that 160 degrees
Colors - 16.7 million

Graphics
XGA - 1024 pixels x 768 lines, H.263), with PCSA DSB1S
4CIF - 704 pixels x 576 lines H.261 Annex D, H.263)

Picture in Picture
Sub Screen Size - 4.3" (256 x 192), one of four corners
Picture in Picture (1)
Main screen size - 17.3" (1024 x 768)
Sub Screen Size - 4.3" (256 x 192), located at upper-right corner of display
Picture in Picture (2)
Main/Sub Screen Size - 10.8" (640 x 480), side-by-side

ITU-T Standards (excludes audio/video standards)
H.320. H.323, H.221, Bonding, H.281 FECC, H.225.0, H.245, T.120
Network Protocols
Telnet (server), HTTP (server), FTP (server), SNMP (Agent), DNS (Client), DHCP (Client), RTP/RTCP, TCP/UDP
Multipoint Video Conferencing Capabilities
Up to 6 sites (H.320/H.323 video conferencing) (Requires optional MCU software. IP/ISDN Bridging is possible.)
Up to 10 sites (H.320/H.323 video conferencing) (Requires optional MCU software. Connections between base units must be IP (H.323). IP/ISDN Bridging is possible.)

Lip Synchronization
Manual on/off

Integrated Camera
Image Device - 1/3 Type CCD
Horizontal Resolution - 450 TV Lines
Focal length - 4.0 mm (F2.0)
Focus - Pan focus
IRIS - Auto (digital AGC)
Zoom Ratio - x2 (digital zoom)
Pan Angle - Minus 35 degrees to plus 35 degrees (digital)
Tilt Angle - Minus 26 to plus 26 degrees (digital)
Preset - Up to 6 positions
S/N - More to 48 dB
Others - Back light compensation, auto white balance

Integrated Microphones
Frequency Response - 15 KHz nondirectional (x 2)

Integrated Speakers
Output - 3W (x 2)

Remote Commander®
Format - Wireless SIRCS

Interface
Video (for office use only) - Composite input, RGB input, D-sub 15
Audio - External microphone input (plug in power), external headphone output (mini-jack)
Audio (for office use only) - Line input (stereo), RCA (x 2), Line input (stereo) mini-jack
Network - 10Base T/100Base-TX, External ISDN Unit I/F
DSB I/F - Dedicated D-Sub 15
Memory Stick - Memory Stick slot

Power Consumption and Requirements
Power Consumption - DC 19.5 V, 7.7 A
Power Requirements - AC 120 V (UC), AC 220 V to 240 V (CE), 50/60 Hz

Weight and Dimensions
Remote Commander Weight - 6.3 oz. (180 g)
Remote Commander Dimensions (W x H x D) - 6 5/8" x 3/4" x 3 ½" (167.4 x 19 x 87.3 mm), excluding projections
Main Unit Weight - 22 lb. 1 oz. (10 kg)
Main Unit Dimensions (W x H x D) - 20 7/8" x 17 5/8" x 4 ¾" (528 x 445 x 110 mm), excluding projections

Humidity and Temperature
Operating Temperature - 5 degrees Celsius to 35 degrees Celsius
Storage Temperature - Minus 20 degrees Celsius to plus 60 degrees Celsius
Operating Humidity - 20% to 80%
Storage Humidity - 20% to 80%

Supplied Accessories
PCS-RTL50 Remote Commander
PCS-AC19V8 AC Adaptor
Manganese battery for Remote Commander (x2)
Operation Guide
Quick Operation Guide
Operation Manual CD-ROM
Worldwide Warranty Card
