Sony PCS-1S Codec - Video Conferencing

Video (PCS-1S Codec)
Signal System - NTSC
Standards - H.261, H.263, H.263+, H.263++, H.264, MPEG-4@L3
Resolution - QCIF, CIF, Interlaced SIF
Frame rate - Max. 30 frames/second
Bit rate - Up to 768Kbps in H.320 (including audio), Up to 2Mbps in H.323 (including audio)

Audio
Bandwidth and Coding
G.711: 3.4kHz at 56/64Kbps
G.722: 7.0kHz at 48/56/64Kbps
G.722.1: 7.0kHz at 24Kbps (H.323)
G.728: 3.4kHz at 16Kbps
G.723.1: 3.4kHz at 5.3/6.3Kbps (H.323)
G.729: 3.4kHz at 8Kbps (H.323)
MPEG-4 AAC mono 14kHz at 64 and 96Kbps (H.323) (line and microphone)
Echo Cancellation
Reduction rate: 30 dB
Echo path length - 340 ms (4kHz and below), 110 ms (4 to 8kHz), 56 ms (8kHz and above)
Noise suppresser included
Automatic gain control included

Graphics
XGA - 1024 pixels x 768 lines (H.263)
4CIF - 704 pixels x 576 lines (H.261 Annex D and H.263 Base)

Picture-in-Picture
Sub screen size: 1/9 (one of four corners)

Network Protocols
TELNET (Server)
HTTP (Server)
FTP (Server)
SNMP (Agent)
PING
DNS (Client)
DHCP (Client)
RTCP
RTP
TCP
ARP

ITU-T Standards
H.320, H.323
H.221, H.239
Bonding
H.281 FECC
H.225.0
H.245
T.120

Multipoint Video Conferencing Capabilities
Up to 6 sites (H.323)
Up to 6 sites (H.320)
Up to 10 sites (H.323) (note: Two PCS-1 units with PCS 323M1 installed must be used.)
Up to 6 sites (H.323 and H.320 combined)

Lip Synchronization
Manual On/Off

Compatible Sony Cameras
EVI D30
EVI D70
EVI D70/W
EVI D100
BRC 300

Compatible Sony Microphones
PCS A1
PCS A300

Remote Commander® Unit
Format - Wireless SIRCS

I/F of PCS-1S
Video
S-video input
Composite input
S-video output (x2)
Composite output
RGB output
Audio
Line input (RCA)
External microphone input (plug in power) (x2)
Line output (RCA) (x2)
Graphics
RGB (XGA) output
Network
10Base- /100Base-TX
Digital Whiteboard
Dedicated Connector (Mimio Xi™)
Memory Stick™
Memory Stick media slot
Control
RS-232C/VISCA™ (mini-DIN 8-pin) for second camera
IR for Remote Commander unit

I/F of PCS DSB1
Audio interfaces
Microphone input (mini jack) (x5)
Line output (mini jack) to active speaker
AUX input (RCA)
AUX output (RCA)
Graphics
RGB (XGA, SVGA, VGA) input (x2)
RGB (XGA) output

I/F of PCS B768
ISDN: BRI (basic rate interface) (x6)

PCS-1S Weight and Dimensions
Communication Terminal - 10.25(W) x 2.25(H) x 6.75(D) in., 2.875 lbs.
Remote Commander Unit - 2(W) x 1(H) x 7.75(D) in., .375 lb. (incl. battery)

Environment
Operating temperature - 5°C to 35°C
Operating humidity - 30% to 70%
Storage temperature - minus 20°C to plus 55°C
Storage humidity- 25% to 75%

Supplied Accessories and System Components
Communication terminal
Camera interface adapter
Remote Commander unit
IR receiver
AC adaptor
IR repeater (x2)
Manganese battery for Remote Commander unit (x2)
Velcro for communication terminal (x2)
Audio cable (1.0 m)
S-video cable (1.5 m)
Operation manual
Warranty card

Consumption and Power Requirement
Consumption - DC 19.5 V, 3.5A
Requirement - AC 120 V, 50/60Hz

Network Certifications
Glowpoint™
Cisco AVVID™
